| Part Type | Filter element |
| Replaces | Sofima CCH3204MN1 |
| Filtration Media | Pleated stainless steel wire mesh |
| Filtration Rating | 125 µm, stainless steel wire mesh |
| Flow Direction | Out-In |
| Seal Material | Fluorocarbon (FKM / Viton) |
| Largest Outer Diameter | 78 mm (3 1/16") |
| Largest Inner Diameter | 40.6 mm (1 19/32") |
| Total Height | 520 mm (20 1/2") |
| End Configuration | Single open end |
| Collapse Rating | 21 bar (305 psid) |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Sofima | CCH3204MN1 |
| Spare Part Mart | SPM-HYD-2492 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving 20-73% on Sofima CCH3204MN1 buying from SPM.
Return line filtration
Return filters clean all the oil coming back to the tank, which is where most wear debris is caught. A clean element keeps the whole circuit healthy.
Industrial power units
Sofima return and tank top filters are fitted to power units on Italian presses, machine tools and plastics machines.
Mobile hydraulics
Agricultural and construction machines from Italian builders use Sofima tank top filters on the main return line.
Planned maintenance stock
Holding a spare element means the change can happen as soon as the clogging indicator trips, not after a parts order.
No. It is an aftermarket element made to the dimensions and filtration grade of the Sofima CCH3204MN1. It is not made by or affiliated with Sofima or UFI, and the Sofima part number is used only to show what it replaces.
Yes if your filter takes the Sofima CCH3204MN1. Check the old element: 78 mm outside diameter, 40.6 mm bore and 520 mm overall length.
The element is pleated stainless steel wire mesh rather than glass fibre, so it is used where coarse protection is needed and the element can be cleaned. Wash it in clean solvent, blow it out from the inside and refit it if the mesh is undamaged.
Fluorocarbon (FKM / Viton) O-rings, which suit mineral oil, synthetic and most fire resistant fluids and higher oil temperatures.
Change it when the filter's clogging indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first.
